Powerful 850W Output: Delivers intense, high-impact projection for large-scale outdoor events.
IP66 Waterproof Rating: Built to withstand rain, dust, and harsh outdoor environments.
OSRAM 800 Module Light Source: Premium chip ensures bright, stable, and long-lasting performance.
Electronic 10°-50° Zoom: Adjustable beam angle for flexible projection from tight to wide.
CMY + CTO Color System: 8 colors plus white with precise color temperature control.
Rotating Gobo Wheel: 7 gobos with forward/reverse rotation and positioning function.
4-Facet Rotating Prism: Creates stunning dynamic prism effects for added visual depth.
8 Controllable Framing Blades: Precise beam shaping with full framing control.
Dynamic Shadow Effect: Adjustable speed shadow for realistic, dramatic projection.
DMX512/RDM Control: Bi-directional signal with standard DMX and manual editing.
Ultra-Quiet 35dB Operation: Keeps the focus on the performance, not the machine.
Conduction Cooling System: Efficient heat dissipation for stable, reliable operation.
Overheat Protection: Full power protection system ensures safe, long-term use.
Real-Time Temperature Monitoring: Keeps light source stable and extends lifespan.
UV & Salt Spray Resistant: Professional outdoor paint for durability in tough conditions.
Quick Gobo Replacement: Easy access window for fast, hassle-free gobo changes.
>90° Tilt Adjustment: Flexible vertical positioning for versatile projection angles.
Waterproof Connectors: XLR male & female with secure, weatherproof signal connection.
Compact & Durable: Measures 567.5×296×353mm and weighs 24 kg net for easy transport.
Professional Grade: Ideal for outdoor concerts, festivals, theme parks, and large-scale events.
Light Source Type: Module Light Source 800
Light Source Chip: OSRAM
Color Temperature: 7500K
Electronic Focus: 10%-0-10% Electronic Focus Adjustment
Strobe Speed: 1-20Hz/s
Beam Angle: 10°-50° Electronic Zoom
Beam Shape: Round
Dimming Curve: 1 Level
DMX Channel Mode: 26 Channels
Connection Method: Daisy Chain Connection
Color System: 8 Colors + White (CMY + CTO)
Shadow Effect: Dynamic Shadow Effect with Adjustable Speed
Gobo System: 1 Rotating Gobo Wheel + 7 Gobos + Open
Gobo Rotation: Forward & Reverse Rotation with Gobo Positioning Function
Prism Effect: Rotating 4-Facet Prism Effect (Custom Prism Available)
Framing System: 8pcs Controllable Framing Blades
Protection Function: Overheat Protection
Control Mode: Standard DMX512/RDM Bi-directional Control Signal + Manual Editing Control System
Tilt Adjustment: >90° Vertical Adjustment
Temperature Control: Real-time Light Source Temperature Monitoring
Other Control: Standalone Auto Running Mode
Maximum Power Consumption: 850W
Input Voltage: AC110-240V, 50/60Hz
Power Factor: PFC >0.98
Noise Level: 35dB (0.5m)
Working Temperature: -25℃ to +35℃
Display: LCD Color Screen, Chinese/English Switching, Screen Rotation
Signal Connection: Waterproof Connector / XLR Male & Female
Cooling System: Conduction Cooling System
Surface Treatment: Professional Outdoor Paint, UV Resistant & Salt Spray Resistant
Gobo Replacement: Quick Gobo Replacement Window
Ventilation: Equipped with Pressure Relief Valve and Ventilation Holes
Power Protection: Full Power Overheat Protection System
Adjustment Method: Manual Adjustment
Housing Material: Aluminum Alloy
Internal Protection: Electronic Moisture-Proof Treatment
IP Rating: IP66
Product Dimension: 567.5×296×353mm
Net Weight: 24KG
